Series 110, XtreamPhase® Liquid/Liquid Phase Coalescers with Single Stage Cartridges

Brand: PECOFacet
The XtreamPhase, Series 110H-WP utilizes a permanent mesh pad design to coalesce the discontinuous phase liquid.

The vessel is designed to include enough space after the mesh pad to allow for gravity separation.

The mesh pads are wafer shaped and come in three different materials with varying removal efficiencies.
show more
The XtreamPhase, Series 110H-WP utilizes a permanent mesh pad design to coalesce the discontinuous phase liquid.

The vessel is designed to include enough space after the mesh pad to allow for gravity separation.

The mesh pads are wafer shaped and come in three different materials with varying removal efficiencies.
Close

Displaying price & availability for Virginia, United States in USD. Change location

6 models matching criteria
110HR-FG-10-285-WP
  • Series - 110HR
  • Wafer Pack Type - FG
  • Nominal Shell Diameter - 10"
  • Design Pressure - 285 psig
In Stock
110H-SS-10-285-WP
  • Series - 110H
  • Wafer Pack Type - SS
  • Nominal Shell Diameter - 10"
  • Design Pressure - 285 psig
In Stock
110H-EX-10-285-WP
  • Series - 110H
  • Wafer Pack Type - EX
  • Nominal Shell Diameter - 10"
  • Design Pressure - 285 psig
In Stock
110HR-EX-10-285-WP
  • Series - 110HR
  • Wafer Pack Type - EX
  • Nominal Shell Diameter - 10"
  • Design Pressure - 285 psig
In Stock
110H-FG-10-285-WP
  • Series - 110H
  • Wafer Pack Type - FG
  • Nominal Shell Diameter - 10"
  • Design Pressure - 285 psig
In Stock
110HR-SS-10-285-WP
  • Series - 110HR
  • Wafer Pack Type - SS
  • Nominal Shell Diameter - 10"
  • Design Pressure - 285 psig
In Stock
Close
Close

Specifications

Brand

Standard

  • 10” to 84” diameter
  • Hydrostatic testing at 1.3 to 1.5 x Design Pressure
  • Basket Internals: Stainless Steel
  • External Attachments: Carbon Steel
  • Pressure Parts: Carbon Steel
  • Swingbolt or Quick Opening Closure
  • Design Pressure 285 psig to 1480 psig
  • Design Temperature from -20° F to 600° F
  • ASME Code Section VIII, Div.1

Options

  • Auxiliary Packages in Stock
  • Optional PECO SafeLock Closure
  • High Design Pressure upon Request

Materials of Construction

  • Other materials on Request
  • 316L Stainless Steel
  • 316 Stainless Steel
  • 304L Stainless Steel
  • 304 Stainless Steel
  • Carbon Steel

Non-Destructive Testing (NDT)

  • Charpy Impact
  • Brinell Hardness
  • Ultrasonic
  • Liquid Penetration
  • Magnetic Particle
  • Radiography

Coating Options

  • Sandblast: commercial, near White and White metal
  • Paint: 2 & 3 Coat corrosion resistant
